ZB-R系列橡膠齒輪泵
發布日期：2014-02-28 11:59:25 | 來源：巴特熔體泵-廣州辦事處 | 瀏覽次數：
ZB-R系列橡膠泵
ZB-R系列橡膠齒輪泵具有高效的自清潔功能，簡潔的設計，優化了流體通道。高壓差下脈動率更低。適用于聚丁橡膠、氯丁二烯橡膠、EPDM、SBR、NBR、天然橡膠等工藝中。
技術參數
泵體: 高溫工具鋼，
齒輪: 高溫工具鋼，滲氮鋼
滑動軸承: 高溫工具鋼
軸封: 螺旋外排
加熱系統 : 電加熱 、熱水加熱
冷卻系統：軸端冷卻系統
規格/流量范圍: 從50CC - 2000CC, 50cm3/rev - 2000cm3/rev
操作參數
粘度: ≤20000 Pas
溫度: ≤130℃
清洗溫度: ≤350℃
進口壓力: ≤20MPa
最高壓差: 可達50MPa
ZB-R Series Rubber Melt Pump
ZB-R series rubber melt pump is efficiently self-cleaning. The structure for shaft sleeves is simple, while the fluid passageway is specially designed. All of this make the pulsation rate become much lower under the higher differential pressure. This series of melt pump applies to butadiene rubber, chloroprene rubber, EPDM, SBR, NBR, natural rubber, etc.
Technical Parameter
Material for Melt Pump Body: High Temperature Tool Steel
Material for Gear: High Temperature Tool Steel or Nitrided Steel
Material for Sliding Bearing: High Temperature Tool Steel
Shaft Sealing: Spiral Discharging
Heating System: Electrical Heating or Hot Water Heating
Cooling System: Shaft End Cooling
Model/Volume Range: 50CC - 2000CC, 50cm3/rev - 2000cm3/rev
Operating Parameter
Viscosity: ≤20000
Working Temperature: ≤130℃
Cleaning Temperature:≤350℃
Inlet Pressure: ≤20MPa
Differential Pressure:≤50MPa
